25Gbps SFP28 AOC Optical Module For High Speed Networking
  • name
  • name
  • name

25Gbps SFP28 AOC Optical Module For High Speed Networking

MOQ: 1 piece
Price: $23-30 / piece
Standard Packaging: box
Payment Method: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Detail Information
Product Description
Detail Information
Place of Origin
Beijing, China
Brand Name
HengzhengTC
Model Number
HZAS25Ax
Use:
Server, Switch, Storage, And Host Card Adapters
Connector Type:
SFP28
Maximum Transmission Rate:
25.78125Gb/s
Operating Temperature:
0~+70℃
Power Supply:
Single 3.3V Power Supply
Power Consumption:
<1.0W
Highlight:

SFP28 optical module

,

AOC optical module

,

25Gbps aoc module

Product Description
25Gbps SFP28 AOC Optical Module for High-Speed Networking
Key Features
  • Hot-pluggable SFP28 form factor
  • Supports 25.78125Gb/s bit rate
  • Maximum link length of 70m on OM3 MMF and 100m on OM4 MMF
  • 850nm VCSEL laser and PIN photo detector
  • Internal CDR on both Transmitter and Receiver channel
  • Operating environment temperature range: 0 ~ +70°C
  • Single 3.3V power supply
  • Low power dissipation: <1.0W
Ordering Information
Part No. Pack Rate(Gbps) Tx(nm) Rx Temp(℃) Reach(m) Fiber Type Pull Tab Color
HZAS25A3 SFP28 25.78125 VCSEL PIN 0~+70 3 OM3 PANTONE Black C
HZAS25A5 SFP28 25.78125 VCSEL PIN 0~+70 5 OM3 PANTONE Black C
HZAS25A7 SFP28 25.78125 VCSEL PIN 0~+70 7 OM3 PANTONE Black C
HZAS25A10 SFP28 25.78125 VCSEL PIN 0~+70 10 OM3 PANTONE Black C
HZAS25A70 SFP28 25.78125 VCSEL PIN 0~+70 70 OM3 PANTONE Black C
HZAS25A3 SFP28 25.78125 VCSEL PIN 0~+70 3 OM4 PANTONE Black C
HZAS25A5 SFP28 25.78125 VCSEL PIN 0~+70 5 OM4 PANTONE Black C
HZAS25A7 SFP28 25.78125 VCSEL PIN 0~+70 7 OM4 PANTONE Black C
HZAS25A10 SFP28 25.78125 VCSEL PIN 0~+70 10 OM4 PANTONE Black C
HZAS25A70 SFP28 25.78125 VCSEL PIN 0~+70 70 OM4 PANTONE Black C
HZAS25A100 SFP28 25.78125 VCSEL PIN 0~+70 100 OM4 PANTONE Black C
25Gbps SFP28 AOC Optical Module For High Speed Networking 0
Packing & Delivery
 25Gbps SFP28 AOC Optical Module For High Speed Networking 1
Why Choose Us
How can we guarantee quality?
✅ Strict Quality Control Process
What can you buy from us?
  • Brocade FC & Ethernet Switches (e.g., Brocade 6505, 6510, G620)
  • QLogic & Emulex HBAs (e.g., QLogic 2562, Emulex LPe31000)
  • Finisar Optical Transceivers (10G/25G/40G/100G, compatible with Cisco, HPE, etc.)
  • Mellanox InfiniBand & Ethernet Adapters (e.g., ConnectX-3/4/5, 10G/25G/100G)
Why should you buy from us not from other suppliers?
✅ Genuine & Reliable Products
✅ Competitive Pricing
✅ Fast & Secure Shipping
✅ Technical Support
✅ Flexible Solutions
Tags:

fiber patch cable,

Ethernet fiber optic cord,

multimode fiber patch cord
